Entities make up the majority of anything that moves inside The Binding of Isaac, from tears to enemies to Isaac himself. This tutorial will cover the basics on creating a custom entity.

Video tutorial

Creating an entity

To create an entity, you will only need an entities2.xml file located within your mod's content folder. There is a lot of content involved with each of the XML's available tags, so this tutorial will cover over them in individual sections.

entities tag

This is the root tag. All entities2.xml files must start and end with this tag.

root entities tag variables

Variable Name	Possible Values	Description
anm2root	str	Root path of the anm2 files used for each entity, set to gfx/ by default.
version	string	The version of the items.xml format. This must always stay equal to 5.
deathanm2	string	Optional. Root path of the anm2 file used for showing death portraits of enemies.

entity tag

This is the tag used to define an entity.

entity tag variables

This list excludes enemy-specific variables. You can find those in the Enemies article.

Note

The majority of variables, for most intensive purposes, are optional. The vanilla entities2.xml file contains more than necessary for every entry.

• name, id, variant, anm2path, friction, and shadowSize are baseline variables for any entity.
• collisionRadius, collisionMass, and numGridCollisionPoints should be included for entities with collision.

Variable Name	Possible Values	Description
name	str	Name of the entity.
id	int	Type of the entity. Max Value: 4095
variant	int	Variant of the entity. The maximum value is 4095. If you leave this blank, then the game will automatically chose the next available number. However, the first available number is commonly 0, so this is not recommended as it may cause issues.
subtype	int	SubType of the entity. The maximum value is 255. (The reason for this is that the hash map generator of the .stb format expects a specific bit-depth.)
anm2path	string	Path to the .anm2 file, relative to the given anm2root. Example: 001.000_Player.anm2
baseHP	int	Base number of hit points the entity starts with. Usually only relevant for enemies, but can be used on other entities.
collisionDamage	float	Amount of damage the player will take when colliding with this entity. 1 = a half heart.
collisionMass	float	The weight of the entity to determine how far it is pushed when another entity collides against it. The higher the number, the heavier they are.
collisionRadius	float	Radius of the collision circle. This value is used for both entity <--> entity and entity <--> grid collisions. This changes the Entity.Size field.
collisionRadiusXMulti	float	Multiplier for the X direction of the collision circle. This can be used to grant an entity an elliptical hitbox.
collisionRadiusYMulti	float	Multiplier for the Y direction of the collision circle. This can be used to grant an entity an elliptical hitbox.
collisionInterval	int	Number of game ticks between checks for collision. Default = 1.
numGridCollisionPoints	int	Number of points along the edge of the collision circle, which are used to detect collisions with grid entities.
friction	float	Slipperiness of the entity. Default = 1. Higher values make them slide more, similar as they would standing on ice. Slower values make them slide less. A value of 0 makes them unable to move.
shadowSize	float	The radius of the shadow underneath the entity.
tags	string	A space-separated list of tags which determine certain properties and behaviors. See more here.
gridCollision	string	Determines how the entity collides with grid objects such as rocks and pots. Note that Effect entities (id >999) never have grid collision. Possible values: ['none', 'nopits', 'ground', 'walls', 'floor'].
gibAmount	int	The amount of gibs the entity will drop upon death. Used for dip familiars. The main method of applying gibs and its amount is used with the gibs tag
gibFlags	string	Used values: ['poop']. Used for dip familiars.

REPENTOGON-only entity tag variables

Variable Name	Possible Values	Description
coinvalue	int	How much this coin pickup is worth when using GetCoinValue (either by the game or a lua call).
customtags	string	Space-separated list of tags added by REPENTOGON which determine certain properties and behaviors. See CustomTags section on the REPENTOGON Docs.
nosplit	boolean	Allows preventing this NPC from being split by Meat Cleaver.

Below is the very first entry inside the vanilla entities2.xml file, defining the player. You can use this as an example, but do not actually define new player entities yourself.

<entities anm2root="gfx/" version="5">
    <entity anm2path="001.000_Player.anm2" baseHP="10" boss="0" champion="0" collisionDamage="0" collisionMass="5" collisionRadius="10" friction="1" id="1" name="Player" numGridCollisionPoints="40" shadowSize="16" stageHP="0" variant="0">
        <gibs amount="0" blood="0" bone="0" eye="0" gut="0" large="0"/>
    </entity>
</entities>

What to set for id/variant/subtype

Firstly, the id, or "type" of the enemy, should be set anywhere from 1 to 1000. Depending on the type of entitiy you're creating, you will want to refer to the EntityType enum.

• IDs 1-9 are for specific, unique entity types, such as the player and projectiles.
• IDs 10-999 are for enemies.
• ID 1000 is custom effects.
• IDs above 1000 will be defined as effects, but may cause issues for not being the standard ID of 1000. More information can be found later below.

variant and subtype are for defining different types of the same entity, which have differing rules dependent on what vanilla entries already exist.

Variant auto-filling

Due to a bug, allowing the variant to auto-fill for Effect entities can have it use the variant for the "star flash" effect. This will cause unexpected behavior for your effect, and can make it not show up or be removed after a short period of time.

If an entity already has a defined variant and you use that variant, your entity may take on some of the properties of that entity variant. For custom variants, simply define a number not taken up by existing vanilla entries.

subtype should always be a number not taken up by existing vanilla entries.

Type overflowing

There is a maximum value you can set for id, variant, and subtype:

• id is capped at 4095.
• variant is capped at 4095.
• subtype is capped at 255.

The values can technically be set higher than these caps, but the game internally condenses all 3 values into a 32-bit integer with a limited amount of space per variable. Amounts higher than the intended cap can cause an overflow to occur, which can cause your entity to start behaving as a different entity if the condensed number lines up with something else. If the condensed value is over the 32-bit integer limit, anything outside those bounds will be lost.

Generally speaking, subtype is safer to allow to overflow, and the vanilla game itself does this for certain enemies. For example, the Ball and Chain enemy uses its subtype as a bitfield for configuration in Basement Renovator. It can still cause issues though, and neither id or variant should ever go over 4095.

This entity entry defines a new tear variant by having its id set to 2. It starts from variant 39, as the last defined vanilla tear variant is 38.

<entity anm2path="my_new_tear_variant.anm2" collisionMass="8" collisionRadius="7" friction="1" id="2" name="My New Tear" numGridCollisionPoints="8" shadowSize="8" variant="39" />

Fetching the ID/variant/subtype of your entity with Lua

Your defined id/variant combination may overlap with other mods that happen to define the exact same combination. The game may assign new variants or new subtypes to compensate for the overlap. As such, it is good practice to fetch them with the following functions instead of directly using the numbers you provided:

• Isaac.GetEntityTypeByName
• Isaac.GetEntityVariantByName
• Isaac.GetEntitySubTypeByName

For subtype, you must either note down the subtype manually, or use REPENTOGON.

Tags explanation

The tag variable is used to define specific behavior for the entity that varies depending on the tag. You can define one or more tags from the list below:

Tag-Name	Suffix
cansacrifice	Marks familiars that Sacrificial Altar can be used on.
nodelirium	Blacklists a boss from being used by Delirium.
fly	Indicates enemies which should be neutralized by Skatole. Does not affect Beelzebub.
spider	Indicates enemies which should be neutralized by Bursting Sack.
ghost	Indicates enemies which Vade Retro can kill at <50% HP.
noreroll	Immunity to Ace cards that turn enemies into pickups. If a devolve tag is defined on the enemy, will prevent rerolls from D10 wisps.
brimstone_soul	Friendly Ball wisps created by this enemy will fire Brimstone lasers.
explosive_soul	Friendly Ball wisps created by this enemy will fire explosive tears.
homing_soul	Friendly Ball wisps created by this enemy will fire homing tears.
devilsacrifice	Repentance+ exclusive tag that allows your item to be paid for with damage instead of heart containers.

entity child tags

The entity tag has numerous child tags to help define additional information about the entity. Only a few are mentioned here, while the others are explained in Creating enemies.

gibs tag

The gibs tag is used to define the gibs that are spawned when an entity is killed or destroyed. The entity will spawn an amount of gibs based on the amount variable and randomly select between one of the other gib variables that are set to 1. The default for the other gib variables is 0 (disabled).

Variable Name	Possible Values	Description
amount	int	How many gibs should be spawned.
blood	int	Red meat/muscle particles.
bone	int	Bone particles.
chain	int	Chain gibs. Only used by The Visage in vanilla.
colorblood	int	Colors blood particles to be colored by the entity's SplatColor.
dust	int	Dust particles.
eye	int	Small eyeball particles.
gut	int	Gut particles (e.g. intestines).
huge	int	Used by the Ultra Horsemen. Causes the screen to shake when the entity is killed and plays a meatier death sound.
large	int	Plays a meatier death sound.
poop	int	Poop particles.
rock	int	Small rock particles.

preload and preload-snd tags

Both of these tags are old remnants of Isaac's code for preloading other entities or sounds when the entity is spawned for smoother loading times when it is spawned/played later by said entity. preload-snd serves no purpose for the PC version of Isaac as all sounds in the game are preloaded when the game launches. It is not known if preload has any useful applications.

preload tag variables

Variable Name	Possible Values	Description
name	str	Name of the entity.
id	int	Id/type of the entity.
variant	int	Variant of the entity.
subtype	int	SubType of the entity.

preload-snd tag variables

Variable Name	Possible Values	Description
id	int	ID of the sound effect.

---
